紅星機器生產的污泥烘干機可將污泥烘干,便于污泥生物有機肥的生產,是有機肥制造企業的 烘干設備。污泥的干化處理,使污泥農用、作為燃料使用、焚燒乃至為減少填埋場地等處理方法成為可能。
Sludge has high humidity, and high adhesion, during the drying process, wet slime are sent into scattered equipment via ribbon conveyor, The massive sludge after scattering are sent into drying chamber dryer of negative pressure to be dried.
污泥烘干機可廣泛應用于活性污泥干燥、下水污泥干燥、石化污泥干燥、造紙污泥干燥、印染污泥干燥、制革污泥干燥、電鍍污泥干燥、市政污泥干燥、生物發酵菌渣等各種污泥及各種糟渣等高濕物料干燥。
Sludge dryer is mainly used to dry slime, raw coal, peat, flotation concentrate, mixed coal, tailings and other materials in coal industry.
污泥由給料機經溜槽進入污泥烘干機內導料板上,隨著筒體的轉動,污泥被導至傾斜揚料板上即被提升到筒體的中心位置,逐漸灑落形成料幕,高溫氣流從中穿過,使污泥預熱并蒸發部分水分。當污泥灑落、移動到活動的篦條式翼板上時,物料又與預熱過的篦條式翼板夾雜在一起,將熱量傳給物料,使部分水分蒸發。同時,翼板夾帶物料提起、灑落,重復多次,物料與熱氣流進行對流和接觸熱交換。同時埋在物料中的清掃裝置,也沿圓弧形揚料板的里側下滑,把揚料板內壁粘附的物料清掃下來。當清掃裝置隨筒體轉過垂直線以后,又在圓弧揚料板背面拖動,將其粘附在揚料板外壁的物料清掃下來。隨著污泥烘干機筒體的不斷轉動,使部分水分蒸發,污泥得到進一步干燥。同時,清掃裝置對污泥團球也起到了打碎作用,提高了干燥速度, 污泥干燥后變成低水分的松散物料,由污泥烘干機出料口排出。
1、污泥烘干機抗過載能力強,處理量大,燃料消耗少,干燥 ;
2、新型給料、排料裝置, 了滾筒干燥機給料堵塞、不連續、不均勻和返料等現象,降低了除塵系統的負荷;
3、采用順流干燥方式,熱效率高;
4、可根據用戶要求控制產品粒度和水分,煤泥烘干成品水分可達 8% 以下,粒度可控制在 8mm 以下;
5、污泥烘干機采用“調心式托輪裝置”,使托輪和滾圈的配合永遠呈線性接觸,從而大大降低了磨損和動力損耗;
6、烘干機 了“零水平推力”,大大減少了擋托輪的磨損,筒體運轉平穩可靠。
1. Sludge dryer has strong anti-overload capability, large quantity management, low fuel consumption, low drying costs;
2. New feeding, discharging devices can prevent phenomenon of clogging of the feed drum dryer, not continuous, not uniform and returning materials, reduce the load of the exhaust system;
3. Adopt downstream drying, high thermal efficiency;
4. Control particle size and moisture according to user requirements, the moisture of sludge drying product reaches to below 8%, particle size can be controlled less than 8mm;
5. Sludge dryer adopts self-aligning roller device, so the roller and rolling ring are linear touched, thus it greatly reduce the wear and power loss;
6. Sludge dryer achieves a “zero thrust” which greatly reduces the wear of roller block, to make sure the smooth and reliable operation of cylinder.
河南紅星礦山機器有限公司位于河南省鄭州市。是一家大型污泥烘干機廠家,生產的污泥烘干機具有布局合理、安裝方便等優點。污泥烘干機價格合理,歡迎新老客戶來廠參觀選購。
污泥烘干機廠家地址:中國-河南-鄭州-高新 產業開發區-檀香路-8號。
